Conformal Coating HASL Pb Free Prototype PCB Assembly Services

Product Categories

Beijing Haina Lean Technology Co., Ltd

Contact Now

Conformal Coating HASL Pb Free Prototype PCB Assembly Services

Name: Conformal Coating HASL Pb Free Prototype PCB Assembly Services
Brand: HNL-PCBA
Price: 1 USD

China Conformal Coating HASL Pb Free Prototype PCB Assembly Services wholesale

Brand Name : HNL-PCBA

Model Number : PCB Assembly

Certification : ISO9001,IS16949, ISO14001,ROHS ,IPC-A ,QC080000

Place of Origin : CHINA

MOQ : 1 PC

Price : Negotiable

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : 10,000,000 Point /Day

Delivery Time : 1-7days

Packaging Details : ESD packaging with carton box

Product name : Prototype Pcb Assembly Services

Layers : Multilayer

Copper thickness : 0.33oz -6oz

Min. line spacing : 0.030mm / 0.030mm

Board thickness : 0.3mm-3.5mm

Min. hole size : Laser 0.05mm ; Mechnical 0.15

Surface treatment : HASL,OSP,ENIG,HASL Lead Free,Immersion Gold

Solder mask color : Green,white,black,red,orange,yellow,blue,purple

Material : FR-4,High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic

Application : communication industry, medical equipments, consumer electronics ,automotive electronics , Elevator,etc.

Contact Now

Conformal Coating HASL Pb-Free Prototype Pcb Assembly Services

Prototype Pcb Assembly Services Introduction

We provide a quality and highly flexible PCB assembly process with fast turnaround. Prototype PCB Assembly (PCBA) is one of our PCB assembly services. With our professional SMT and DIP soldering team, and experienced components sourcing specialists, For becoming a leading PCB assembly prototype manufacturer and provider, we are equipped with advanced machines including solder paste printer, solder paste inspection, SMD placement, AOI,DIP, X-ray and etc.

Factory Capacity

No.	Items	2020
1	HDI Capabilities	HDI ELIC(5+2+5)
2	Max layer count	36L
3	Board Thickness	Core thickness 0.05mm-1.5mm ,Fineshed board thickness0.3-3.5mm
4	Min.Hole Size	Laser 0.05mm Mechnical 0.15
5	Min Line Width/Space	0.030mm/0.030mm
6	Copper Thickness	1/3oz-6oz
7	Size Max Panel size	700x610mm
8	Registration Accuracy	+/-0.05mm
9	Routing Accuracy	+/-0.05mm
10	Min.BGA PAD	0.125mm
11	Max Aspect Ratio	10:1
12	Bow and Twist	0.50%
13	Impedance Control Tolerance	+/-5%
14	Daily output	4,000m2 (Max capacity of equipment)
15	Surface Finishing	ENEPING /ENIG /HASL /FINGER GOLD/IMMERSION TIN/SELECTIVE THICK GOLD
16	Raw Material	FR-4/Normal Tg/High Tg/Low Dk/HF FR4/PTEE/PI

Our service

1.PCB Design & Layout 2.PCB Prototyping 3.PCB Fabrication 4.Turnkey Prototype PCB Assembly
5.PCB Assembly Service 6.Contract PCB Assembly 7.Trunkey PCB Assembly 8.Components sourcing

9.Function test 10.conformal coating 11.complete assembly

Conformal Coating HASL Pb Free Prototype PCB Assembly Services

SMT capabilities

SMT Assembly: SMT provides a flexible high technology.
These solutions include:
7 high-speed placement machines, 7 automatic printers with fiducial alignment, 2 X-ray machines, BGA maintenance machines, ICT test machines

DIP function

A-8 semi-assembly production line with four wave soldering machines
1 U-shaped automatic assembly line for box-type building products with test stations
High temperature / low temperature aging test furnace B-4 for products required for aging test
With time control and temperature control
All products are 100% inspected and tested during the DIP process

Conformal Coating HASL Pb Free Prototype PCB Assembly Services

Prototype Pcb Assembly Application

Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics ,automotive electronics , Elevator,audio and video, optoelectronics, robotics, hydroelectric power, Elevator,aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.

Conformal Coating HASL Pb Free Prototype PCB Assembly Services

Delivery Time

Product Type	Qty	Normal lead time	Quick-turn lead time
SMT+DIP	1-50	1WD-2WD	8H
SMT+DIP	51-200	2WD-3WD	1.5WD
SMT+DIP	201-2000	3WD-4WD	2WD
SMT+DIP	≥2001	4WD-5WD	3WD
PCBA(2-4Layer)	1-50	2.5WD-3.5WD	1WD
PCBA(2-4Layer)	51-2000	5WD-6WD	2.5WD
PCBA(2-4Layer)	≥2001	≥7WD	5WD
PCBA(6-10Layer)	1-50	3WD-4WD	2.5WD
PCBA(6-10Layer)	51-2000	7WD-8WD	6WD
PCBA(10-HDILayer)	1-50	7WD-9WD	5WD
PCBA(10-HDILayer)	51-2000	9WD-11WD	7WD

Common packaging

PCB: Vacuum packaging with carton box
PCBA: ESD packaging with carton box

Conformal Coating HASL Pb Free Prototype PCB Assembly Services

Company Introduce

Haina Lean Electronics is providing high quality bare PCB,PCB layout design service and PCB assembly service,including components sourcing, function test,conformal coating and complete assembly for clients all.
We have profuse experience in manufacturing PCB,owned experienced technical R & D technology team, young and professional sales and customer service team, experienced and professional procurement team and assembly testing team, which make sure the products quality of the pass rate, on-time delivery rate of customer orders.
Our services include: circuit board design and layout, 2-46 layers PCB manufacturing, professional FPC production, electronic components purchasing, SMT professional processing, Soldering and Assembly, especially sample and small bulk orders. we have the advantages of a quick quote, fast production, fast delivery.
